Polaris RZR XP Turbo/S STM 50-34 Helix

Name: Polaris RZR XP Turbo/S STM 50-34 Helix
SKU: 403FU0029

The helix is the “brain” of the driven clutch and it will respond differently with a change in load to the machine, for example, bigger tires or increasing gross weight to the vehicle. With the 36-42 helix, you will gain more out of your driven clutch and have a quicker backshift compared to the OEM helix while raising your rpms and top speed.

Does not fit 2021 Pro XP

SKU: 403FU0029

$63.00

Quantity

Subtotal: $63.00

Quantity must be 1 or more

Description
Disclaimer

Description

The helix lives within the secondary clutch. The helix helps apply pressure to the CVT drive belt. There are two types of helixes, straight and progressive. Straight helixes will have the same angle cut the whole duration. A progressive helix with have two different cuts for different shift points. Different helixes with more aggressive or less aggressive angles can adjust the pressure on the belt and shift points. If you get too aggressive with the helix angle, and don’t adjust the secondary spring you will cause belt slip. If your rpms are too low, a shallower range helix and/or stiffer secondary spring will raise rpm. This will also provide more squeeze on the belt which is useful if you are experiencing belt slip. Conversely, if your rpms are too high, a steeper range helix and/or softer secondary spring will lower rpm.

Polaris RZR XP Turbo/S STM 50-34 Helix
